Infrared Heat Lamp for Printing Equipment

415V 3300W twin tube ir lamps for drystar heidelberg

G4.170.0101 replacement IR Lamp
Voltage 415V
Power 3300W
Bulb Twin
OAL 740mm
INQUIRY

Short-wave, 23mm x 11mm quartz w/ gold reflector

3300 Watt, 415 Volt

740mm (29.13″) OAL

Heated Channel #1: 670mm (26.37″)

Heated Channel #2: 670mm (26.37″)

Type B: Full coils, wired series, 500mm (19.68″) leads

USED IN: Speedmaster 52, SM52, Heidelberg MO, DryStar Dryer Lamp # G4.170.0101/ 53.170.1311

Please kindly note that all of our products are replacements and not original items, these are custom made by ourselves but with same function quality and more competitive prices.

For all orders, we will ship within 2 weeks.

Victoria product code: 69413351

Specifications:

Twin Tube Infrared Heat Lamp
Total Length(mm)	Heated Length(mm)	Voltage(V)	Wattage(W)	Cross Section(mm)	Reflector	Connection Side	Burning Position	TYPE
125	60	115/230	600	23X11	GOLD	VERTICAL	ONE-SIDE	B
145	80	115/230	600	23X11	GOLD	VERTICAL	ONE-SIDE	B
145	80	115/230	1000	23X11	GOLD	VERTICAL	ONE-SIDE	B
200	130	230	1200	23X11	WHITE	HORIZONTAL	ONE-SIDE	B
250	180	240	1000	23X11	GOLD	HORIZONTAL	ONE-SIDE	B
350	270	240	1500	33X15	GOLD	HORIZONTAL	ONE-SIDE	B
400	320	230	2000	23X11	GOLD	HORIZONTAL	TWO-SIDE	C
450	380	400	2200	23X11	NO	VERTICAL	TWO-SIDE	C
480	410	230	2000	33X15	GOLD	HORIZONTAL	ONE-SIDE	B
500	420	400	3000	23X11	WHITE	HORIZONTAL	TWO-SIDE	C
600	535	230	3000	23X11	GOLD	HORIZONTAL	ONE-SIDE	B
630	560	380	3600	23X11	GOLD	HORIZONTAL	TWO-SIDE	C
660	580	400	4400	23X11	NO	HORIZONTAL	ONE-SIDE	B
700	630	220	3000	23X11	GOLD	HORIZONTAL	TWO-SIDE	C
735	630	400	4600	33X15	GOLD	VERTICAL	TWO-SIDE	C
800	700	230	4000	23X11	GOLD	HORIZONTAL	TWO-SIDE	C
900	800	400	6950	23X11	GOLD	HORIZONTAL	TWO-SIDE	L
1100	1000	400	3500	23X11	GOLD	HORIZONTAL	ONE-SIDE	A
1125	1020	400	6000	23X11	GOLD	HORIZONTAL	ONE-SIDE	B
1160	1080	400	6200	33X15	GOLD	HORIZONTAL	ONE-SIDE	B
1200	1100	240	5400	23X11	GOLD	HORIZONTAL	ONE-SIDE	G
1250	1150	400	3500	23X11	GOLD	HORIZONTAL	TWO-SIDE	D
1450	1350	400	8000	23X11	GOLD	HORIZONTAL	TWO-SIDE	C
1700	1600	480	9000	23X11	GOLD	HORIZONTAL	TWO-SIDE	C
2200	2100	480	12800	33X15	WHITE	HORIZONTAL	TWO-SIDE	C
3100	3000	480	13000	33X15	GOLD	HORIZONTAL	TWO-SIDE	C

Alternative Models


Part no.	Volts	Watts	OAL	Type
09751720	400	3000	1100	A
09751713	115	600	145	B
09751751	230	1500	300	B
09751741	230	1200	405	B
09751740	400	3000	600	B
09751340	400	3000	600	B
09751761	230	3000	650	C
09751765	230	4200	850	C
09751760	400	6000	1150	C
09751731	400	7000	1450	C
09751780	400	6000	1450	D
09751783	400	5000	1850	D
09752439	230	500	400	B
09755167	230	1000	900	B
09755054	230	2000	900	B
09755255	230	2500	1100	B
09753187	230	3250	1420	B
09754585	230	3750	1600	B
09754863	400	4100	1800	B
09754783	400	4500	1920	B
09756083	400	5750	2400	B
09753874	230	6250	2600	B
09753923	400	2500	1300	C
09752912	400	4000	1700	B
09754619	400	5000	2120	B
09753874	400	6250	2600	B
09751473	400	4800	1150	B
09751471	400	4000	1150	B
09751474	400	9500	2250	C
09751472	400	4800	2715	A
09751475	400	9600	2750	C

Heidelberg
Machine	Alt part no.	Voltage	Wattage	TOL	Type
Speedmaster 74	M6.170.0301/01	400	6950	900	L
Speedmaster 74	SM74-FMW-B	480	4200	900	B
Speedmaster 52	G4.170.0101	415	3300	740	B
M Offset/ MO	53.170.1311	415	3300	740	B
Speedmaster 102	91.170.1311	415	3500	1100	A
Speedmaster 102	C7.170.0301/01	400	5400	1200	H
Speedmaster 102	91.170.1411	415	2500	1100	B
Speedmaster 102	SM102-FMW-B	480	6000	1125	B
Speedmaster 102	F7.170.0771	400	6200	1160	G
Speedmaster 72	83.170.1311	415	3500	800	B
Speedmaster 72	83.170.1411	415	1900	800	B
XL105	F7.170.0771.01	400	6200	1160	G

We also have the ability to design and produce other kinds of infrared heating lamps according to your requests.

Donghai Young Light Technology Co., Ltd is a professional manufacturer specialized in producing infrared heating lamps over 15 years. All of our infrared heating lamps can meet the testing standard of CE, RoHS. Custom made is available in our factory, same specification as HERAEUS, DR. FISCHER, GE etc.

We also provide OEM/ODM service of different designs IR heating lamps, and ensure the good quality with on time delivery. Our heating lamps are exported to more than 50 countries include Germany, UK, USA, Mexico, Brazil, Egypt, Turkey, South Korea and other Asian countries. We manufacture singe tube IR heating lamps and twin tube IR heating lamps and sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation.

If you want to order or have any questions, please provide the following technical parameters or tell us your heating requests, we will reply you within 24 hours.

Total length LT=?
Heated length LH=?
Voltage=?
Wattage=?
Cross section= 23×11mm or 33×15mm
Reflector= Gold or White ceramic
Burning position= Horizontal or Vertical
Lamp type or original photo
